Basic parameter indicators:

Channel size 500(W)×300(H)mm

Conveyor speed 0.22m/s (adjustable)

Conveyor rated load 150 kg

Resolution 0.101 mm diameter metal wire (0.0787 mm diameter metal wire) (0.078 mm diameter metal wire)

Penetration force 10 mm steel plate (38 mm steel plate) (40 mm steel plate)

Film safety Safe for ISO1600 film

Leakage dose <0.05μGy/h

射線束方向 底照式

X-Ray Generator:

Ray beam direction Undershot type

Tube current 0.4~0.5mA (adjustable) (0.6~0.8mA adjustable) (0.4~0.5mA adjustable)

Tube voltage 80 KV (adjustable) (125 KV adjustable) (160 KV adjustable)

Ray beam divergence angle 60°

Cooling / duty cycle Sealed oil cooling / 100%

X射線傳感器 L形光電二極管陣列探測器 (單能量)(多能量)，12bit深度

Image processing system:

X-ray sensor L-shaped photodiode array detector (single energy) (multi-energy), 12bit depth

Display high-resolution 17-inch LCD monitor

Color image display 24-bit true color display

Edge enhancement Object contour edges more clearly

Super Image Enhancement Sharper image details

High-penetration display Improves contrast in bright areas of the image, making easy-to-penetrate areas clearer

Low-transmission display Improves contrast in dark areas of the image, making difficult-to-penetrate areas clearer

Magnifier local magnification function

Brightening/darkening Increasing the brightness of the image/darkening the brightness of the image

Image pull back/forward Display of the first 20 images and any image processing can be performed on the current image

Image recovery Restore the image display to its original state

Image storage Save any image in real time and perform any image processing, continuous working storage

工作溫度／濕度 0℃～45℃／20%～95% (不冷凝)

噪聲級 <60dB

Operating environment:

Operating temperature / humidity 0℃～45℃／20%～95% (non-condensing)

Storage temperature / humidity -20℃～60℃／20%～95% (non-condensing)

Operating voltage 220VAC(±10%)? 50±3HZ

Power loss 1.0KW (maximum)

Noise level <60dB
